Review of the ColorChecker from X-Rite...

We recently did a commercial shoot and used the ColorChecker Passport from X-rite for the very first time and I can tell you this, I wish I had started using this a LONG time ago.

It could not have been easier to use or worked better at giving us perfectly matched colors in our images.

We were shooting new products for our clients catalog/website and it involved almost 100 images in a wide variety of colors.

Using the Lightroom "color picker" to color correct an image will allow me to apply the changes to the other LIKE images, but once I try to apply the changes I made to a primarily purple colored product to an image with the primary colors of yellow or red it just doesn't cut it, so Iend up creating and applying color correction based on the primary colors of the photograph.

Labor intensive at the least, with a bunch of frustration stirred in.

With the ColorChecker Passport you correct one image and then simply sync up every other image shot under the same lighting conditions, regardless of the images dominant color.

It was SWEET.

This image is one of the products being shot on white seamless with the ColorChecker Passport in the frame (the black cinefoil was used to block shiny reflections caused by the white paper), all the images were imported into Lightroom, we color corrected this image and because all were shot under the same lighting conditions we simply "synced" all other images with this and we were done (with color management) with everything we shot that day.


This image shows a side by side comparison of a product shot "as is" and color corrected using the ColorChecker Passport, clicking on it will open the image larger (in a new window) so you can better see the comparison.


You have heard me preach in the past about good time management, studio efficiencies, and basically being as smart as you can with the one thing you have the most control over, TIME.

The ColorChecker Passport is now at the top of my list when it comes to efficient workflow.

Just to show you it could not be easier, here are the instructions from the X-Rite website:

* Open the Raw image of the ColorChecker target that you previously shot.
* Do not edit the image. In fact, any edits will be ignored when you begin building the profile.
* Under the File menu, select Export… When the menu appears, select “ColorChecker Passport” from the list.
* Enter a name for the profile and click the Export button.

The new profile will be created automatically and placed in the location where Adobe stores DNG profiles for Camera Raw and Lightroom. You will need to re-launch Lightroom before you can select the new DNG profile. After restarting Lightroom follow the steps below.

* With an image selected, go to the Develop module.
* In the right panel, scroll down to Camera Calibration and select the Profile pull-down. Choose the new DNG profile you created above from this list.
* To apply these settings to an entire series of photos select all the other images you shot in the same lighting conditions and hit "Sync".


When you can give all the instructions a user needs in under 10 lines of text, you have a product that is easy to use.

But it's more than that, it will give you perfect color too. What a great combination.

Purchasing the ColorChecker passport will say many things about you, like getting the color correct is really important... and that you are smart with both your time and your money.

I will leave you with a product demonstration video for Lightroom users, you can find the Photoshop version here. (And as usual subscribers will need to return to the blog to watch the video)



5 comments:

half blind said...

I just saw a webinar with the photographer using the passport. It looks great, quite useful. I'm saving up!

Miguel Palaviccini said...

This does look like the tool to use for ANY sort of studio photography. Talk about being efficient with time!

Scott, check the video though as it's no longer working. :(

faris said...
This comment has been removed by the author.
faris said...

i just bought this colorchecker passport and i was so excited to get it working but somehow im frustrated by the result. I'm also shooting products which is color specific. I would like to have closest color possible.

I'm not sure where I've done wrong. FYI, my setup includes : 2 flash and 2 continuous lights (soft daylight, each at left & right). On of the flash on top of the light tent and the other is in front of the prorudct (same as where i sit to take picture).

1. Is there anything wrong? Is it because i have too much lighting sources?
2. when i take a picture should i compensate for the flash brightness (take with slight underexposed)
3. Im shooting RAW and edit in LR. Does the EV compensation in the camera make a diff to the colorchecker color?

sorry for the long post. thanks in advance. cheers!

Scott said...

Faris,

Here are two YouTube links for you, the first is creating a profile in Lightroom:

http://www.youtube.com/watch?v=KLLDiuUp8cw

The second shows how t use that profile in Lightroom:

http://www.youtube.com/watch?v=WUBio7jXtWc

Lastly, here is the ColorChecker support page (click on the support tab):

http://xritephoto.com/ph_product_overview.aspx?id=1257&catid=28&action=overview

I hope this helps you out.

Scott
